Fast speed, compact camera for: Vehicle Impact, Airbag Deployment and Safety Restraints Testing, Projectile, Ballistics, Combustion and Missile Launch Tracking, Fluid and Flow Visualization, Sports Broadcasting, Commercial Film, Television and Studio Production, Flat panel inspection (FPD), printed circuit board (PCB) examination and more.

Specifications:
Resolution	1.1 MP 1280 × 864 pixel
Sensor type	CMOS B/W monochrome
Sensor model	Luxima LUX13HSM
Sensor size	4/3"
Sensor active area	17.5 × 11.8 mm
Pixel size	13.7 μm
Bits per pixel	10
Dynamic range	60 dB
Frame rates	3500+ Fps
Image data interface	PCI Express (PCIe) Gen3
Data I/O	2IN/2OUT
Power requirements	17 Watt
Cooling	Fan
Lens mount	Active EF-mount
Weight	268g
Dimensions WxHxD	60 x 70 x 55 mm
Customs tariff code	8525.80 30 (EU) / 8525.80 40 (USA)
ECCN	EAR99
